Real-time PCR Analyzer Pointcare® PCR V2
To satisfy the increasing demands of molecular detection, PCR instruments need to deliver fast-cycling protocols and accurate, sensitive results. MNCHIP Pointcare® PCR V2 Real-Time PCR System is designed for users who need an affordable, easy-to-use real-time PCR system that doesn’t compromise performance and quality. The simplified design and analysis software is ideal for both first-time and experienced users. For quick and accurate test results delivered where needed, when needed, improving the efficiency of operations and providing a flexible, long-term solution.
Sales Support
Service Support
Features & Benefits
![产品宣传单页PCR-12](https://en.mnchip.com/wp-content/uploads/2023/11/产品宣传单页PCR-12-7.png)
![产品宣传单页PCR-13](https://en.mnchip.com/wp-content/uploads/2023/11/产品宣传单页PCR-13.png)
![产品宣传单页PCR-14](https://en.mnchip.com/wp-content/uploads/2023/11/产品宣传单页PCR-14.png)
More efficient
Unique multiplex PCR technology allows
simultaneous detection of up to 5
pathogens in a single reaction tube,
enhancing diagnostic efficiency.
Easier to use
Built-in ultrasonic mixing device to
replace manual mixing, reducing
the need for manual manipulation.
More accurate
Internal control added to PCR reaction tube
effectively avoids false negatives; probe-based
method used for double confirmation of target
sequences, ensuring higher specificity.
Test Kits
![](https://en.mnchip.com/wp-content/uploads/2023/11/产品宣传单页PCR-16.jpg)
![](https://en.mnchip.com/wp-content/uploads/2023/11/产品宣传单页PCR-17.jpg)
* More test kits coming soon…
10 Tests/Box
Operation
![mM1009](https://en.mnchip.com/wp-content/uploads/2021/11/mM1009.png)
Obtain sample
![mM1010](https://en.mnchip.com/wp-content/uploads/2021/11/mM1010.png)
Transfer sample to tube
![产品宣传单页PCR-18](https://en.mnchip.com/wp-content/uploads/2023/11/产品宣传单页PCR-18.png)
Insert tube and start test
![产品宣传单页PCR-19](https://en.mnchip.com/wp-content/uploads/2023/11/产品宣传单页PCR-19.png)
Read results
Technology
![mM1017](https://en.mnchip.com/wp-content/uploads/2021/11/mM1017.png)
MNCHIP fluorescence-based Real-time PCR utilizes a bottom-illumination optical detection system and repeated thermal cycling for DNA detection. Each cycle involves three steps: denaturation, annealing, and extension. By continuously collecting fluorescence data using TaqMan detection principle, the system automatically draws real-time amplification curves.
Specifications
Dimensions:210mm(L)×125mm(W)×175mm(H)
Weight:About 2.0kg
Sample Type: Nasopharyngeal and Oropharyngeal Swab, Anal Swab, Fecal Swab, Blood, Ascites, etc.
* Please refer to package inserts for details.
Reaction Volume: 20μL
Test Time: 30-90 minutes
Sample Throughput: 1 wells
Light Source: High power, maintenance-free LED.
Detector: Photodiodes
Operation Temp: 10-30°C
Operation Humidity: 40-85%
Power Supply: 24V
